Marshall Amplification VMV-402-SH User Manual

3
Model Name
VMV-402-SH Quad-viewer/Switcher
Role of Usage
Quad-viewer or 4x1 Video Switcher
Video Input Support
[3G] 1080p @50/59.94/60Hz (4:2:2)
[HD] 720p @50/59.94/60Hz, 1080i @50/59.94/60Hz, 1080p
@24/30/60Hz
Audio Pass Through
Embedded surround sound (up to 7.1ch) or stereo digital audio
Input
4x BNC [SDI]
Program Output
1x HDMI + 1x BNC(SDI)
HDMI connector
Type A [19-pin female]
RJ-45 connector
WE/SS 8P8C
ESD Protection
Human body model — ±12kV [air-gap discharge] & ±8kV
[contact discharge]
Mechanical
Housing
Metal enclosure
Mounting
1U rack-mounting case with ears
Dimensions [L x W x H]
8.25” X 7” X 1.75”
209mm X 178mm X 44.5mm
Weight
1Kg (2.2 lbs) with rack ears
Power supply
12 - 24 Volts DC
Power consumption
12 Watts nominal
0.5 amp at 24 volts 1 amp at 12 volts
Operation Temperature
0~40°C [32~104°F]
Storage Temperature
-20~60°C [-4~140°F]
Relative Humidity
20~90% RH [no condensation]
5. Specifications
