Installation and Initial Setup
Unpacking
Carefully unpack the V-LCD171MD monitor and verify tha he following items are included:
• V-LCD171MD Monitor (3G Module Oponal)
• V-PS12-5V-XLR Power Supply
• Operang Instrucons
Inspec he uni or any physical damage that may have occurred during shipping. Should there be any damage, immediately
contact Marshall Electronics at (800) 800-6608. If you are not located within the connental United States, call +1 (310) 333-
0606.
Connections, Power-On and Initial Setup
Plug the power supply into an AC power source (100-240 V @ 50/60 Hz). Aach the Power connector to the back o he monitor.
Connec he required cables for video signal input and output. (Power must be applied to the V-LCD171MD for the acve loop-
though outpu o be acvated.) The monitor defaults to ‘ON’ when power is supplied. Video will automacally be detected and
displayed on the screen.
