(7) WSX set-up for very high power dance/rock production on large
thrust stage
front view
side view
Gives narrow vertical & wide horizontal coverage up to 120Hz for audience on 3 sides - allowing for
ground effects - with tighter apron WSX spacing for more coherent nearfield mid-bass coverage and
punch.
1) Set the front & rear WSX arrays to match the main front & rear corner system farfield
levels around 120Hz
2) Set the front & rear W8Cs to balance the main systems + WSXs in the nearfield
3) Set the flown centre W8Cs to balance the main systems + WSXs + W8Cs in the L, R &
centre/mix position midfield areas
4) Set the apron W3s to fill the L, R & centre nearfield region
5) Set the apron WSXs to match the W3s around 120Hz
Island stages (not shown)
Island stages are simply four-sided versions of examples 3 and 5 and should be
aligned using the same process.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
