2.2Specifications
W8CT
Type: Dedicated longthrow high-mid/high enclosure
Frequency response: 750Hz-18kHz +/- 3dB
Drivers: 3 x 6.5" (165mm) high-mid horn
6 x 1" (25mm) exit hf compression driver
Rated power: High-mid 450W AES, 1800W peak
High 360W AES, 1440W peak
Sensitivity: High-mid 113dB
High 115dB
Maximum SPL: High-mid: 139dB continuous, 145dB peak
High: 141dB continuous, 147dB peak
Impedance: High-mid: 6 ohms nominal
High: 2 x 6 ohms nominal
Coverage (-6dB): 55º horizontal, Line vertical (see Section 2.8)
Crossover: 750Hz, 3.5kHz
Connectors: 2 x Neutrik NL8
Cabinet construction: Birch Ply
Cabinet finish: Slate textured paint
Protective grille: Perforated steel
Grille finish: Grey paint
Dimensions (incl wheels): (W) 562mm x (H) 799mm x (D) 925mm
(W) 22.1ins x (H) 31.5ins x (D) 36.4ins
Flown weight: 81kg (178lb). Lid 4kg (9lb) extra
W8CM
Type: Dedicated longthrow low-mid enclosure
Frequency response: 120Hz-750Hz +/- 3dB
LF limit: -10dB @ 80Hz
Drivers: 2 x 12" (305mm) low-mid horn
Rated power: 600W AES, 2400 peak
Sensitivity: 109dBspl/W
Maximum SPL: 136dBspl continuous, 142dBspl peak
Impedance: 4 ohms
All material © 2007. Martin Audio Ltd. Subject to change without notice.
