Cabinets may be fitted with rear hinge back plates to allow removable hinges to be
slotted in place. These hinge assemblies provide a more rigid rear cabinet alignment.
For further information please refer to the Martin Audio Wavefront 8 Flying System
User Guide.
Rigging Schools!
Rigging should not be undertaken by untrained or unqualified personnel.
Suitable rigging training sessions may be arranged by calling Martin Audio Ltd on
+44 (0)1494 535312.
Important note on flown systems examples
Wavefront cluster examples are included in this manual to illustrate recommended
loudspeaker combinations and splay angles only. Note that very large clusters -
particularly those including Wavefront Longthrow elements - may need to be flown
in multiple layers to maintain the 12:1 safety factor of the standard Martin Audio
Wavefront 8 Flying System.
SAFETY NOTE!
Two female "keyhole" stud plates are fitted to each side of Wavefront cabinets to
allow cabinets to be flown up-side-down for certain applications. The upper keyhole
is the only one ever used - whatever the configuration.
