Single W8 on W8S subwoofer
This very compact stack may be used as one side of a main system for a folk band
concert in a small venue, one corner of a small dance floor system, stage side fills,
stage drum fills, front fills etc.
SAFETY REMINDER!
Stacks should always be safety strapped to allow for high winds, over-exuberant
artists, crowd indicipline, scenery movements etc.
Wide coverage, broadband stack
Although a single Wavefront W8’s horizontal coverage is 55º at high frequencies, the
system has been designed to integrate well with smaller splays for practical output
summing. A splay of 40º between axes (260mm between cabinet front corners)
provides very smooth 95º horizontal coverage with little increase in mid-band output
level whilst a smaller splay angle can boost the forward output level by 2-3dB.
2-wide W8/W8S ground-stack
All material © 2007. Martin Audio Ltd. Subject to change without notice.
