standard W8C cluster extending its low frequency response to below 45Hz. This
configuration can be very efficient as it uses the rest of the cluster as a baffle,
increasing forward projection allowing high gain before feedback.
The following iconic layout may be used to represent the above cluster:
30
20 20 20 20
20 20 20
20
Important reminder:
Splay angles are always quoted axis-to-axis - not between cabinet sides!
ie. 30 =
|‹ 30º ›|
30 30
30 30 30
30
30
30
30 30 30
