2.9 Further examples
Wavefront Longthrow columns may be horizontally arrayed for wide coverage:
30
(left & right clusters will be mirror image)
High-mid/high horizontal coverage would be
1/2 left W8CT + 30º + 30º + 1/2 right W8CT
= one W8CT +30º + 30º
= 55º + 60º
= 115º.
30
30
30
30
30
30
30
