5.5.6 Array Type
The choice of loudspeaker type depends on the application. See W8L Series
Applications Guide Section 5.4
If a mixed system is selected a further section to the right allows you to define the
quantity of the lower cabinets.
5.5.7 Array Fixing
Select either Fly or Stack in the Fixing section to determines how the array is
supported.
In Fly mode the grid is suspended and cabinets are attached beneath
In Stack mode the grid forms a base and cabinets are placed on top. Ground
Stack Bars are fixed between the grid and the rear splay holes of the lowest
cabinet to set the overall system tilt.
