Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE User Manual

Coverage (-6dB): 55º horizontal, Line vertical (see Section 2.8)
Crossover: 120Hz, 750Hz
Connectors: 2 x Neutrik NL8
Cabinet construction: Birch Ply
Cabinet finish: Slate textured paint
Protective grille: Perforated steel
Grille finish: Grey paint
Dimensions (incl wheels): (W) 562mm x (H) 799mm x (D) 925mm
(W) 22.1ins x (H) 31.5ins x (D) 36.4ins
Flown weight: 72kg (158lb). Lid 4kg (9lb) extra
Before rigging, note colour coding! W8C has 2 black points per side
W8CS has 1 black point per side
W8CT has 2 orange points per side
W8CM has 1 orange point per side
All material © 2007. Martin Audio Ltd. Subject to change without notice.
