Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE - Page 136

134dB cont.,
140dB peak.
HF:
136dB cont.,
142dB peak.
129dB cont.,
135dB peak.
HF:
129dB cont.,
135dB peak.
125dB cont.,
131dB peak.
Passive
124dB cont.,
130dB peak.
Nominal Impedance
LF: 8 ohms
MF: 8 ohms
HF: 8 ohms
LF: 8 ohms
MF: 8 ohms
HF: 8 ohms
Bi-amplified
LF+MF:
12 ohms
HF:
12 ohms
Passive
12 ohms
Crossover
LF to MF:
220Hz active,
MF to HF
2.5KHz active
LF to MF:
300Hz active,
MF to HF
3KHz active
LF to MF:
300Hz passive,
MF to HF
2.2KHz active
or passive
Connectors
2 x Neutrik
NL8 or PAcon
sockets
(Input & Link)
2 x Neutrik
NL8 or PAcon
sockets
(Input & Link)
2 x Neutrik
NL4 sockets
(Input & Link)
Enclosure
Vertical
trapezoid
3.75 deg top &
bottom walls.
Multi-laminate
birch ply
Vertical
trapezoid
3.75 deg top &
bottom walls.
Multi-laminate
birch ply
Vertical
trapezoid
3.75 deg top &
bottom walls.
Multi-laminate
birch ply
Finish
Textured paint Textured paint Textured paint
Grille
Perforated
steel
Perforated
steel
Perforated
steel
Dimensions mm
inches
(*incl wheelboard)
(W) 1314
(H) 490
(D) 755/855*
(W) 51.7
(H) 19.3
(D) 29.7/33.7*
(W) 1000
(H) 367
(D) 550/683*
(W) 39.4
(H) 14.5
(D) 21.7/26.9*
(W) 620
(H) 241
(D) 400
(W) 24.4
(H) 9.5
(D) 15.75
Weight (incl. steel hardware)
127Kg
(279lbs)
58Kg (128lbs) 24Kg (53lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
