Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE User Manual

5.5.3 Using ViewPoint
tm
Once you have installed ViewPoint
tm
, it will be visible as a shortcut in All Programs
via your Windows Start button.
A single click on the viewpoint v3.03 tab will open the following page:
ViewPoint
tm
will indicate splay angles and controller presets for these flown systems:
W8L (Full-range line array)
W8LS (Sub-woofer)
W8LC (Compact line array)
W8LM (Mini line array)
WLX (Sub-woofer)
and these flown combinations of the above:
W8LS (Sub) above W8L
W8L above W8LC
W8LS (Sub) above W8LC
W8LC above W8LM
WLX (Sub) above W8LC
WLX (Sub) above W8LM
and the following ground-stacks:
All material © 2007. Martin Audio Ltd. Subject to change without notice.
