Recommended W8 pairs:
Inner Farfield Outer Farfield
Inner Midfield Outer Midfield
Inner Nearfield Outer Nearfield
Inner DownfieldOuter Downfill
Controller channel allocations
The whole cluster may be controlled from just ½ a Martin Audio DX1 controller set
up for 3-way operation. See Section A1.5 for further DX1 information.
Power amplifier channel allocations
There are 8 pairs of W8 loudspeakers each requiring high, high-mid & low-mid
power amplifier channels.
8 pairs at 3 bands per pair = 24 amplifier channels required
= 12 x 2ch amplifiers per cluster
All material © 2007. Martin Audio Ltd. Subject to change without notice.
