Wide coverage cluster
4 or 6 wide, 4 deep W8C clusters may be rigged for very wide coverage. Coverage
may be calculated as follows:
6 wide cluster
The horizontal coverage now extends to:
55º+30º+30º+30º+30º+30º = 205º for 30º horizontal splays
55º+40º+40º+40º+40º+40º = 255º for 40º horizontal splays
and the vertical coverage extends to:
30º+15º+15º+15º = 75º for 15º vertical splays
30º+20º+20º+20º = 90º for 20º vertical splays
6 wide, 4 deep plan view
