Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE User Manual

W8CS - assuming 800Wcont - 1600Wpk into 8ΩΩ power amplifiers:
Best-fit Recommended
Amplifier Amplifier Amplifier DX1 LIMITER
Example Sensitivity Gain Settings
dBu Vrms dB dBu
Crown MA5002VZ (0.775v) -2 0.62 42 -3
Martin MA4.2** (41dB) -1 0.69 41 -2
Crest CA18 (x115) -1 0.69 41 -2
Crown MA3600VZ (0.775v) -1 0.69 41 -2
0 0.77 40 -1
+1 0.87 39 0
+2 0.98 38 +1
+3 1.09 37 +2
QSC PL236/PL236A (36dB) +4 1.23 36 +3
+5 1.38 35 +4
+6 1.55 34 +5
+7 1.73 33 +6
Martin MA4.2** (32dB) +8 1.95 32 +7
Crest 8001 (x40) +8 1.95 32 +7
Crest 9001 (x40) +8 1.95 32 +7
QSC PL236A (32dB) +8 1.95 32 +7
+9 2.18 31 +8
+10 2.45 30 +9
+11 2.75 29 +10
+12 3.08 28 +11
+13 3.46 27 +12
Crown MA3600VZ (26dB) +14 3.88 26 +13
Crown MA5002VZ (26dB) +14 3.88 26 +13
QSC PL236A (26dB) +14 3.88 26 +13
** Set Martin Audio MA4.2 rear MLS switch to 0dB to match peak output of
unregulated power amplifiers.
Use lower settings (or more subwoofers!) if your power amplifiers indicate clipping
on more than just the odd peak. Excessive clipping may also be caused by inadequate
power amplifier reserve or an inadequate mains supply. See Section 3.6.
