Martin MAC 300 - Personality and Configuration Settings

Fixture Settings
1 0
Personality settings
The MAC 300’s personality settings are shown in Table 3; they are described as well in the following section. To select
a personality setting:
1.
Press [Menu] as required to reach the main menu. Navigate to
PERS
and press [Enter].
2.
Navigate to the desired setting and press [Enter].
3.
Select the desired option with the arrow keys and press [Enter].
Custom personality configurations
Three sets of custom personality configurations can be stored for later recall. To create and use a custom configuration:
1.
Set the personalities as desired.
2.
Navigate to
PERS
/
dFSE
and press [Enter].
3.
Select
CUS1
,
CUS2
, or
CUS3
and press [Enter].
4.
Select
SAVE
to create a custom configuration or
LOAd
to recall. Press [Enter].
5.
To load the factory default personality settings, navigate to
PERS
/
dFSE
/
FACT
and press
[Enter].
Personality Path Options Effect
(Default setting shaded, * indicates DMX override)
Pan/tilt swap
PATI/SWAP
ON
Map DMX pan control to tilt channel and vice versa.
OFF
Normal pan and tilt control.
Pan inverse
PATI/PINV
ON
Reverse DMX pan control (right
Æ
left).
OFF
Normal pan control (left
Æ
ÆÆ
Æ
right).
Tilt inverse
PATI/TINV
ON
Reverse DMX tilt control (down
Æ
up).
OFF
Normal tilt control (up
Æ
ÆÆ
Æ
down).
Pan/tilt speed
PTSP
FAST
Optimize movement for speed.*
SLOW
Optimize movement for smoothness.*
DMX lamp off
dLOF
ON
Enable DMX lamp off command.
OFF
Disable DMX lamp off command.
*
DMX reset
dRES
ON
Enable DMX reset command.
OFF
Disable DMX reset command.*
Automatic lamp on
ALON
ON
Lamp strikes automatically within 90 seconds of power on.
OFF
Lamp remains off until “lamp on” command is sent.
Display on/off
dISP
ON
Display stays on.
OFF
Display goes out 2 minutes after last key press.
Display intensity
dINT 10
-
100
Adjust display intensity.
Dimmer mode
dMOd
NORM
Normal dimming.
TUNG
Simulated tungsten dimming.
Shortcuts
SCUT
ON
Color and CMY wheels turn the shortest direction.
*
OFF
Wheels turn same direction.*
Effects feedback
EFFb
ON
Enable feedback on color and CMY wheels.
OFF
Disable feedback on color and CMY wheels.
Tracking algorithm
TRAC/MOdE
MOd1
Absolute delta value algorithm (for most controllers)
MOd2
Real delta value algorithm
Tracking samples
TRAC/CAL 1-10
Tracking samples. Increase if pan/tilt is not smooth.
Table 3: Personality settings
