RDM
The MAC Encore Performance can communicate using RDM (Remote Device Management) in accordance
with ESTA’s American National Standard E1.20-2006: Entertainment Technology RDM Remote Device
Management Over DMX512 Networks.
RDM is a bi-directional communications protocol for use in DMX512 control systems, it is the open standard
for DMX512 device configuration and status monitoring.
The RDM protocol allows data packets to be inserted into a DMX512 data stream without affecting existing
non-RDM equipment. It allows a console or dedicated RDM controller to send commands to and receive
messages from specific fixtures.
RDM UID
Each MAC Encore Performance has a factory-set RDM UID (unique identification number) that makes it
addressable and identifiable in RDM systems. The number can be found in the control panel
INFORMATION menu under RDM UID.
RDM communication
The MAC Encore Performance supports the standard RDM PIDs (Parameter IDs) required by ESTA plus a
range of manufacturer-specific PIDs. Sending SUPPORTED_PARAMETERS and
PARAMETER_DESCRIPTION commands from an RDM controller will call up a list of the PIDs supported in
the firmware version installed in the fixture.
The PIDs in the following tables are supported in software v.1.0.0. Additional PIDs will be supported in later
firmware versions.
Standard RDM Parameter IDs
GET
allowed
SET
allowed RDM parameter ID’s (slot 21-22) Notes
Network Management
DISC_UNIQUE_BRANCH
DISC_MUTE
DISC_UN_MUTE
Status Collection
 QUEUED_MESSAGE
 STATUS_MESSAGES
 STATUS_ID_DESCRIPTION
 CLEAR_STATUS_ID
RDM Information
 SUPPORTED_PARAMETERS
 PARAMETER_DESCRIPTION
