Adjustments
MZ034
English
5
142
5.10 TAS (Travel Adjustment System)
The TAS cartridge offers, in addition to the ability
to adjust the rebound damping “on the fly” by
reducing the fork’s length while keeping 30 mm of
travel (see par. 5.9 ETA (Extension Travel
Adjustment)), the possibility of modifying the
maximum travel and fork length so they can be
adapted to the rider’s needs and frame’s
geometry.
WARNING!
Before using to the TAS cartridge adjustment,
you will have to completely deflate the positive
air chamber located on the right leg, and then
re-establish the correct working pressure.
• By turning the knob located at the bottom of the
fork’s leg clockwise, you will reduce the
maximum travel and the fork’s length.
• By turning the knob located at the bottom of the
fork’s leg counterclockwise, you will increase the
maximum travel and the fork’s length.
WARNING!
Never force the knob past its limit, as the fork
could be damaged, resulting in an accident,
personal injury or death.
5.11 TST (Terrain Selection Technology)
The TST system allows for adjustment of the
suspension damping.
The TST cartridge consists of a rebound adjuster,
located in the lower area, and a 5-position
compression adjuster, located in the upper area.
This allows the rider to obtain the best setting
according to the type of trail.
The adjuster located in the upper area has five
main positions: (CL), (+), (AM), (-), and (DS).
Thanks to these 5 positions, the rider can quickly
obtain the best setting according to the type of trail
(see Table 8).
Table 8 - TST Control Positions Table
WARNING!
NEVER us the “CL” position while riding
downhill as the fork will not react properly
when hitting obstacles, and can result in a
loss of control of the bicycle, an accident,
personal injury, or death.
5.12 TST cartridge with remote control
The TST cartridge can be provided, on request,
with a remote control to be installed on the right
side of the handlebar.
The remote control lets the riders lock the fork
while keeping their hands on the handlebar.
The remote control consists of an operating
lever and a release button.
By pulling the control lever, the fork is locked as
it occurs when the TST knob is turned to the
“CL” position. The fork’s locking is independent
of the position of the TST adjustment knob on
the fork.
Once the fork has been locked, by operating the
release button, you reset the fork to the position
set with the TST adjuster.
WARNING!
NEVER us the “CL” position while riding
downhill as the fork will not react properly
when hitting obstacles, and can result in a
loss of control of the bicycle, an accident,
personal injury, or death.
D
S
Best setting for downhill
-
Best setting for “All Mountain”
A
M
+
C
L
Best setting for uphill, locked fork
