Summarizing tables
MZ034
English
6
151
Table 13 - All Mountain
All Mountain
All Mountain
SL
All Mountain I
All Mountain II
All Mountain I
ETA
All Mountain III
Legs’ diameter ø 32 mm
Available travels
130 mm-150
mm*
130 mm-150 mm*** 150 mm 130 mm
Wheel dropout type Standard
Max disk dimension Post Mount 6” **
V-brake fit No
Max wheel
dimensions
2.8” x 26”
* adjustable by changing the negative air
** The installation of 8" disk is only possible when the specific adapter is supplied by the brake system
manufacturer
*** adjustable with TAS
All Mountain II All Mountain III
Positive air - Both legs (Only on right leg for version with + ETA /
+ TAS option)
Remove the protection cap.
Tighten the pump on the valve and inflate till reaching the pressure
you wish. Refit the protection cap
All Mountain SL All Mountain I All Mountain I ETA
Positive air - TST cartridge - Right leg
Remove the rubber protection cap marked with “AIR” and turn the
TST adjuster till uncovering the air valve.
Tighten the pump adapter on the valve and inflate till reaching the
pressure you wish. Refit the rubber protection cap and re-adjust with
the TST adjuster
All Mountain SL
Positive air - DOPPIO-AIR cartridge - Left leg
Unscrew and remove the protection cap.
Tighten the pump adapter on the external valve and inflate till
reaching the pressure you wish. Retighten the protection cap.
AIR
AIR
AIR
