Summarizing tables
MZ034
English
6
157
Table 15 - 66
66
66 SL
66 RC2X - 66 Light
66 VF - 66 VF2
66 VF2 LT
Legs’ diameter ø 35mm
Available travels 150 mm - 170 mm* 150 mm - 170 mm 190 mm
Wheel dropout type ø 20mm through-hole axle
Max disk dimension
Post Mount 6” (The installation of 8" disk is only possible when the specific adapter
is supplied by the brake system manufacturer
)
V-brake fit No
Max wheel
dimensions
2.8” x 26”
* adjustable by changing the negative air
66 Light
Positive air - Left leg
Remove the protection cap.
Tighten the pump on the valve and inflate till reaching the pressure
you wish.
Refit the protection cap
66 SL
Positive air - DOPPIO-AIR cartridge - Left leg
Unscrew and remove the protection cap.
Tighten the pump adapter on the external valve and inflate till
reaching the pressure you wish.
Retighten the protection cap
66 SL 66 Light
Positive air - RC2 cartridge - Right leg
Remove the protection cap marked with “AIR”.
Tighten the pump adapter on the valve and inflate till reaching the
pressure you wish.
Refit the protection cap
AIR
AIR
AIR
