Day of Month
2
6,7
1 to 31
Day of Week
1
8
1 to 7
Hours
2
9,10
0 to 23
Minutes
2
11,12
0 to 59
GMT Marker
1
13
0 or 1
Validity Marker
1
14
0 or 1
CR [Carriage return]
1
15
Non displayable
character
LF [Line Feed]
1
16
Non displayable
character
Table 11-3 NGTS Time string format
11.1.4 GPZDA Time frame output:
masTER T-Sync Model MTS200 transmits GPZDA time frame from COM2 terminal at rear panel of unit at
every 1 second at 9600 (baud rate), 8 (Data bits), N (NONE parity), 1 (1 stop bit). User can change the
serial communication settings using keypad on unit front panel as explained in section 9 or console base
configuration utility as explained in section 9.2 or webserver as per section 13.4 or snmp as per section
13.3.
Note: masTER T-Sync Model MTS200 can be configured to transmit T-format, NGTS, GPZDA or GPGGA
time frame through its COM2 terminal at rear panel. Configuration of frame type can be done via keypad,
via console based configuration utility through serial console terminal or Telnet or SSH, via SNMP or via
Webserver. Refer respective sections in manual for further details.
The full data message of this format shall consist of data fields as follows:
Field
Example
Comments
String ID
$GPZDA,
UTC Time
130525.00,
hhmmss.ss,
UTC Date
29,
Utc date dd
UTC Month
09,
Utc month mm
UTC year
2015,
Utc year yyyy
Local Timezone polarity
+,
Local timezone offset w.r.t. UTC
Local Timezone hours
05,
Local timezone hour w.r.t. UTC
Local Timezone minutes
30,
Local timezone minutes w.r.t. UTC
*cs
xx,xx
Two bytes crc
Terminator
<CR>,<LF>
Non-displayable characters
Table 11-4 GPZDA Time string format
11.1.5 GPGGA Time frame output:
mas TER T-Sync Model MTS200 transmits GPGGA time frame from COM2 terminal at rear panel of unit
at every 1 second at 9600 (baud rate), 8 (Data bits), N (NONE parity), 1 (1 stop bit). User can change the
serial communication settings using keypad on unit front panel as explained in section 9 or console base
configuration utility as explained in section 9.2 or webserver as per section 13.4 or snmp as per section
13.3.
Note: masTER T-Sync Model MTS200 can be configured to transmit T-format, NGTS, GPZDA or GPGGA
time frame through its COM2 terminal at rear panel. Configuration of frame type can be done via keypad,
via console based configuration utility through serial console terminal or Telnet or SSH, via SNMP or via
Webserver. Refer respective sections in manual for further details.
