Model: MTS200 (1U)
Doc. Ref. no. : m08/om/201
Issue no. : 03
User’s Manual Page 14 of 195 Page 14 of 195
Output: TTL into 250 Ω
Pulse Width: 200 (200 mS High & 800 mS Low signal)
Interface: BNC Female connector(Rear Panel)
No. of Ports: 1
Alarms
Three Isolated Dry Contacts to 230 VAC / 24VDC, 10 A:
1. GPS Lost
2. Watchdog
3. Power Fail
Interface: 8-Way Terminal Strip
Event/RTC ON
One Event per minute or per hour or RTC ON/OFF (Configurable)
Interface: 8-Way Terminal Strip (Rear Panel)
Event contact capacity: 350V DC, 120mA maximum
IRIGB-TTL - DC Level Shift / IEEE 1344/C37.118-2005
Format: IRIG-B(007) [IRIGB TTL] or IEEE 1344/C37.118-2005 (field
selectable)
Output: TTL into 50 Ω
Interface: BNC Female connector (Rear Panel)
No. of Ports: 1
Serial
COM1
Protocol: NMEA-0183 (RMC)
Port Settings: 9600-8-N-1
Output: RS232/RS485** (Factory Configurable)
Interface: DB9 Female Connectors (Rear Panel)
No. of Ports: 1
COM2
Protocol: NGTS / T-Format / GPZDA / GPGGA
Port Settings: 1200/2400/4800/9600/19200-7/8-N/E/O-1/2 (Configurable)
Output: RS232/RS485** (Factory Configurable)
Interface: DB9 Female Connectors (Rear Panel)
No. of Ports: 1
** RS232 is factory set
OPTIONAL
OUTPUTS
IRIGB-TTL - DC Level Shift / IEEE 1344/C37.118-2005
Format: IRIG-B(007) [IRIGB TTL] or IEEE 1344/C37.118-2005 (field
selectable)
Output: TTL into 50 Ω
Interface: BNC Female connector (Rear Panel)
No. of Ports: 1
IRIGB-Modulated / IEEE 1344/C37.118-2005
Format: IRIG-B(127)or IEEE 1344/C37.118-2005 (field selectable)
