Masmio W1 Appendix
Masimo Corporation 15 www.masimo.com
Communication (Bluetooth)
Max Peak Output Power -3.6dBm or 0.44mW (Conducted)
Antenna Peak Gain +3dBi
Radio Compliance
Radio Modes Bluetooth LE
USA Model: W1
FCC ID: VKF-MASIW1
Model: Masimo Wireless Charger
FCC ID: VKF-MASIW1CG
Guidance and Manufacturer's Declaration
Electromagnetic Emissions
Equipment is intended for use in the electromagnetic environment specified below. The customer or the user of the ME Equipment should assure that it is used in such an environment.
Emission
Test
Compliance Electromagnetic Environment - Guidance
RF Emissions
CISPR 11
Group 1
Equipment uses RF energy only for its internal function. Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic
equipment.
RF Emissions
CISPR 11
Class B
Equipment suitable for use in all establishments including domestic establishments.
Electromagnetic Immunity
Equipment is intended for use in the electromagnetic environment specified below. The customer or the user of the Equipment should assure that it is used in such an environment.
Immunity Test IEC 60601 Test
Level
Compliance
Level
Electromagnetic Environment - Guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
+6 kV contact
+8 kV air
+6 kV contact
+8 kV air
Floors should be wood, concrete or ceramic tile. If floors are covered with synthetic material, the relative humidity should be at
least 30%.
Power frequency (50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m 30 A/m Power frequency magnetic fields should be at levels characteristic of typical location in a typical hospital environment.
Radiated RF IEC 61000-4-3 10 V/m 80 MHz to
2.7 GHz
10 V/m Portable and mobile RF communications equipment should be used no closer to any part of the Masimo W1, including cables,
than the recommendation separation distance calculated from the equation applicable to the frequency of the transmitter.
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be
predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in
the location in which the Equipment is used exceeds the applicable RF compliance level above, the Equipment should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as re-orienting or relocating the Equipment.
Test Specifications for Enclosure Port Immunity to RF Wireless Communication Equipment
Test Frequency
(MHz)
Band (a)
(MHz)
Service (a) Modulation (b) Maximum Power
(W)
Distance
(m)
Immunity Test Level
(V/m)
385 380-395 TETRA 400
Pulse modulation (b)
18 Hz
1.8 0.3 27
450 430-470 GMRS 460, FRS 460
FM (c)
+/- 5 kHz deviation
1 kHz sine
2 0.3 28
710
704-787 LTE Band 13, 17
Pulse modulation (b)
217 Hz
0.2 0.3 9
745
780
810
800-960 GSM 800/900, TETRA 800, iDEN 820, CDMA 850, LTE Band 5
Pulse modulation (b)
18 Hz
2 0.3 28
870
