Masport P36-3 Gas Inbuilt 7
Because of the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in Diagrams 1 & 2.
COMBUSTIBLE MANTELS
These drawings are to scale at 1:6 (one inch = 6 inches)
Mantel can be installed anywhere in shaded area or higher using the above scale.
Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour.
Also the material from which the mantel is made from must be heat resistamt to 85
o
C.
Diagram 1 Diagram 2
INSTALLATION
