Owner’s Guide
GENERAL SPECIFICATIONS
MODEL: MVR2X
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
MOTOR
AC 48V 4 KW / AC 48V 5KW
Charger:
48V18A Delta Q On Board charger / Smart Charger 48V 25A
Electrical System:
Leoch Brand, AGM Battery 8V 180Ah/3HR * 6 PCS
Drive Train:
Direct motor shaft connected to transaxle pinion shaft
Brakes:
Rear Drum Brake or four wheels hydraulic brake
Body Protection:
PP Plastic Molded Material
Technical Specification
Dimensions
Performance
Overall Length
124 In (3160 mm)
Seating Capacity
4
Person
Overall Width
49.6 in (1260 mm)
Dry Weight
837.76 lb( 380 kg) (Without Batteries)
Overall Height (NO Canopy)
N/A
Curb Weight
1336.87 lb (620kg)
Overall Height (With Canopy)
81 in (2050 mm)
Vehicle load capacity
794 lb (360 kg)
Wheel Base
65.74 in (1670 mm)
Minimum turning radius
10.1ft (3.1m)
Front Wheel Track
Intersecting Aisle Clearance
N/A
Rear Wheel Track
39 in (1000 mm)
Maximum speed (Level
Ground)
15.53 mph (25 km/h)
Ground Clearance @
Differential
6.7 in (170 mm)
Towing Capacity
N/A
Vehicle Power Steering & Suspension
Power Source
48 Volts Steering
Rack and pinion
Motor Type
AC
Front Suspension
McPherson independent suspension
Horsepower (kW)
AC 4 KW / AC 5 KW
Rear Suspension
Trail Arm Suspension
Electrical System
48 Volt
Service Brake
Mechanical brake // Hydraulic brake
Batteries (Qty, Type)
6, 8 Volt Deep Cycle
Parking Brake
Mechanical foot parking
Key YES
Front Tires
22*10-10 // 22*11-12
Speed Controller
AC 1232SER 400A// AC
1234SE 450A
Rear Tires
22*10-10 // 22*11-12
Drive Train
Motor Shaft Direct Drive
Body & Chassis
Transaxle
N/A
Frame
Welded Steel. powder coat and electrophoresis
Gear Selection
Dash Mounted Forward-Neutral-Reverse
Body & Finish
Injection molding
Rear Axle Ratio
12.31:1 / 14.2: 1
Standard Color
Color according to order requirements
Some items shown may be optional equipment
