INTRODUCTION
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
INTRODUCTION
CONTROLS AND INDICATORS
Vehicle controls and indicators consists of: (Figure 1)
1. Gear Switch button (DS-A2-2 L6e Model has Three Postion, D N R)
2. Speedometers
3. Speedometers Cover
4. Headlight Switches Button
5. Hazard Lights Switch Button
6. USB Port as power supply
7. Ignition Key Switch
8. Mechanical Parking Pedal
9. Brake Pedal
10. Accelerator Pedal
11. Tow Switch & Curtis Controller Connector
12. DU-CA500 Model Rear Cargo bed Up and Down Control button
13. Windshield Wiper Spray control button
14. Hydraulic brake system Brake Pedal
15. Hydraulic brake system Accelerator Pedal
16. Hydraulic brake system Foot Parking pedal
Figure 1 Vehicle controls, features and indicators
Owner’s Guide 25
DU-CA500 & All Standard
Massimo Series Golf carts
