- Frequency response: 10 ~ 10 kHz
- Input voltage range: ≥ 1 V rms AC
- Input impedance: 10MΩ
- Max. input voltage: 750V rms AC
3.2.6.3 By Hz/DUTY range
- Frequency response: 1 ~ 10MHz
- Input voltage range: ≥ 500mV rms
- Overload protection: 250V rms AC
3.2.7 Resistance
Range Resolution Accuracy
400Ω 0.1Ω
± (0.8% of rdg + 3digits)
4kΩ 0.001kΩ
40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MkΩ
40MΩ 0.1MΩ ± (1.2% of rdg + 3digits)
- Open circuit voltage: 0.4V
- Overload protection: 250V DC or rms AC
3.2.8 Diode
Range Resolution Function
0.001V Displaying approximate forward
voltage of diode
- Forward DC current ~ 1mA
- Reversed DC voltage ~ 3.3V
- Overload protection: 250V DC or rms AC
- 14 -
3.2.9 Continuity
Range Resolution Function
0. 1Ω Built-in buzzer will sound, if
resistance is lower than 40Ω.
- Open circuit voltage ~ 1.2V
- Overload protection: 250V DC or rms AC
3.2.10 Capacitance
Range Resolution Accuracy
40nF 0.01nF
400nF 0.1nF
4µF 0.001µF ± （ 4.0% of rdg + 5 digits ）
40µF 0.01µF
400µF 0.1µF
4000µF 1µF
- Overload protection: 250V DC or rms AC
- 15 -
