replace the battery as soon as the battery
indicator ( ) appears.
Before replacing the battery, disconnect test
leads and/or any connectors from any circuit
under test, turn the meter off and remove
test leads from the input terminals.
To
replace the battery (see Figure 2.):
( Turn the meter off.
( Disconnect test leads and/or any connectors from the terminals.
( Use a screwdriver to unscrew the two screws secured on the battery cover.
( Take out the battery cover from the meter.
( Remove the used batteries.
( Replace with the new 9V batteries (6F22).
( Rejoin the battery cover and secure by the two screws.
9V Battery
9V Battery
9V Battery
9V Battery
Battery cover
Battery cover
Battery cover
Battery cover
Figure 2. Battery and Fuse Replacement
CAUTION
Using this appliance in an environment with a strong radiated radio-frequency electromagnetic field
(approx. 3V/m), may influence its measuring accuracy. The measuring result can be strongly deviating
from the actual value.
