Owner’s Manual 7
Hardware List
Hardware listed above is not scaled to exact size.
(A screwdriver is required for assembly and is included for your convenience).
AA: 1 PC BB: 14 PCS CC: 14 PCS
Wrench M5 × 10 Bolt M5 Spring washer
DD: 14 PCS EE: 14 PCS FF: 1 PCS
Flat washer M5 Nut M6X7Bolt
GG: 7 PCS HH: 7 PCS II: 6 PCS
M6 Spring washer Flat washer M6 Nut
JJ: 1 PC KK: 2 PCS LL: 2 PCS
Screwdriver R pin Lid pin
