Cleaning and Maintenance
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
You should inspect the burner at least once a year or immediately after any of the following conditions occur:
1. The smell of gas in conjunction with the burner flames appearing yellow.
2. The appliance does not reach temperature.
3. The appliance heats unevenly.
4. The burner makes popping noises.
WARNING:
ENSURE that the gas supply and the knob are in the “OFF” position BEFORE cleaning the burner.
DISASSEMBLE THE BURNER
1. Turn o the gas supply and make sure the knob is in the “OFF” position then disengage regulator from cylinder.
2. Wait for the appliance to cool.
3. Open the lid and remove the basket, flame tamers and grease collector. This will expose the burner from inside.
4. Remove the burner fixing bolts as shown in Step A below.
5. Disconnect electrode wire from the gas valve as shown in Step B below.
6. Remove the burner from the appliance.
Step A
Step B
