13
WICK REPLACEMENT
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
7
8 & 9
4. Gently pull the wick adjustment knob off the heater.
5. Remove the cabinet base by lifting it from the back and
tilting it forward to clear the wick adjuster assembly.
6. Trip the pendulum on the automatic safety shutoff
system to lower the wick.
4
5
6
7. Remove the four wing nuts which hold the wick
assembly to the heater and carefully lift the wick assembly
from the heater.
8. Replace the wick adjustment knob temporarily. Turn the knob
CLOCKWISE to raise the wick.
Wick Cover
9. Hold the wick assembly up-side down, using caution, grasp
the wick cover rmly PULL it off with a sharp tug. If you have
difculty doing so, try loosening the wick cover with a at blade
screwdriver.
CAUTION : The inside of wick cover has sharp teeth. The
use of work gloves is suggested to avoid injury.
To Next Page
