Master MH-80T-KFA - Parts List; Replacement Parts Catalog

NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2018 Pinnacle Climate Technologies, Inc. Kerosene Forced Air Heater User’s Manual
13
PARTS LIST
TIP: To order parts call 800-641-6996.
#
Description 45-KFA 80T-KFA 140T-KFA 190T-KFA 215T-KFA
1
Drain Bolt
–
–
70-002-0115 70-002-0115 70-002-0115
2
Fuel Gauge
70-007-0110 70-007-0110 70-007-0215 70-007-0215 70-007-0215
3
Fuel Filter
70-003-0100 70-003-0100 70-003-0200 70-003-0200 70-003-0200
4
Fuel Cap - Large Plastic
70-006-0140 70-006-0140 70-006-0140 70-006-0140 70-006-0140
5
Power Cord
70-034-0100 70-034-0100 70-034-0205 70-034-0205 70-034-0205
6
Power Switch
70-038-0100 70-038-0100 70-038-0100 70-038-0100 70-038-0100
7
Thermostat Control Knob
– 70-031-0100 70-031-0100 70-031-0100 70-031-0100
8
Air Line
70-035-0100 70-035-0200 70-035-0300 70-035-0400 70-035-0500
9
Thermostat Limit Control
70-019-0100 70-019-0100 70-019-0100 70-019-0100 70-019-0200
10
Photocell Bracket
70-010-0101 70-010-0101 70-010-0101 70-010-0101 70-010-0101
11
Fuel Line
70-036-1010 70-036-1010 70-036-1020 70-036-1030 70-036-1040
12
Photocell
70-016-0100 70-016-0100 70-016-0100 70-016-0100 70-016-0100
13
Burner Head Assembly
70-014-0101 70-014-0101 70-014-0301 70-014-0301 70-014-0301
14
Nozzle Kit
70-015-0100 70-015-0205 70-015-0310 70-015-0410 70-015-0500
15
Spark Plug Kit
70-052-0100 70-052-0100 70-052-0200 70-052-0200 70-052-0200
16
Motor
70-021-0500 70-021-0500 70-021-0510 70-021-0520 70-021-0520
17
Pump Body
70-020-0101 70-020-0101 70-020-0101 70-020-0401 70-020-0401
18
Rotor Kit
70-022-0100 70-022-0100 70-022-0100 70-022-0200 70-022-0200
19
End Pump Cover
70-020-0102 70-020-0102 70-020-0102 70-020-0102 70-020-0102
20
Filter Kit
70-054-0100 70-054-0100 70-054-0100 70-054-0100 70-054-0100
21
End Filter Cover
70-020-0103 70-020-0103 70-020-0103 70-020-0103 70-020-0103
22
Pump Adjustment Kit
70-055-0100 70-055-0100 70-055-0100 70-055-0100 70-055-0100
23
Capacitor
70-020-0125 70-020-0125 70-020-0200 70-020-0201 70-020-0201
24
Fan
70-024-0100 70-024-0200 70-024-0300 70-024-0400 70-024-0400
25
Ignitor
70-037-0350 70-037-0350 70-037-0350 70-037-0350 70-037-0350
26
Fan Guard
70-016-0700 70-016-0700 70-016-0200 70-016-0200 70-016-0200
27
Main PCB Assembly
70-027-0100 70-027-0200 70-027-0300 70-027-0300 70-027-0300
28
Fuse
70-027-0101 70-027-0101 70-027-0101 70-027-0101 70-027-0101
29
Clip Nut
70-001-0106 70-001-0106 70-001-0106 70-001-0106 70-001-0106
30
Air Pressure Gauge
– 70-025-0100 70-025-0100 70-025-0100 70-025-0100
31
Cord Bushing
70-033-0100 70-033-0100 70-033-0200 70-033-0200 70-033-0200
32
Handle
70-001-0103 70-001-0103 – – –
33
Front Handle
– – 70-042-0100 70-042-0200 70-042-0200
34
Rear Handle
– – 70-043-0105 70-043-0205 70-043-0205
35
Wheel Support Frame
– – 70-041-0101 70-041-0201 70-041-0201
36
Wheel Axle
– – 70-041-0115 70-041-0205 70-041-0205
37
Wheel
– – 70-041-1400 70-041-1400 70-041-1400
38
Wheel Nut
– – 70-041-0550 70-041-0550 70-041-0550
39
Hardware Kit (not pictured)
70-056-0100 70-056-0100 70-056-0210 70-056-0210 70-056-0210
40
Cord Wrap
70-032-0100 70-032-0100 70-032-0200 70-032-0200 70-032-0200
41
Motor Supporter
70-020-0600 70-020-0600 70-020-0610 70-020-0610 70-020-0610
