Masterbuilt 20070211 - Assembly - Panel and Handle; Securing Control Panel; Attaching Rear Handle

7
ASSEMBLY
STEP 3
Secure control panel (6) to smoker
body (1) with phillips screws (A).
Note: Do not over tighten.
STEP 4
Attach rear handle (7) to back of
smoker body (1) using phillips
screws (A) as shown.
NOTE: Do not lift unit by rear handle.
6
A
A
A
1
7
