MasterCraft 052-1899-2 - DC Current Specifications; AC Current Specifications

DC CURRENT
Overload Protection:
For "mA°C" jack inputs: Fuse, 500 mA/300 V, fast action
For "10A" jack inputs: Fuse, 10 A/300 V, fast action
Max. Input Current: 10 A (For inputs > 5 A: measurement
duration<10 secs, interval >15 minutes)
Max. Voltage Drop: 400 mV
RANGE
400 μΑ
4000 μΑ
40 mA
400 mA
4 A
10 A
0.1 μΑ
1 μΑ
10 μΑ
100 μΑ
1 mA
10 mA
±(1.2% + 3)
±(1.8% + 3)
±(2.0% + 5)
RESOLUTION ACCURACY
AC CURRENT
RANGE
400 μΑ
4000 μΑ
40 mA
400 mA
4 A
10 A
0.1 μΑ
1 μΑ
10 μΑ
100 μΑ
1 mA
10 mA
±(1.5% + 5)
±(2.0% + 5)
±(2.5% + 5)
RESOLUTION ACCURACY
14
TECHNICAL SPECIFICATIONS
