Measuring DC or AC Voltage
Connect the black test lead to the "COM" jack and the red test
lead to the "VΩHz " jack.
Set the range switch to the "V " range.
Press "FUNC" button to select DC or AC voltage measurement.
If you use manual range mode and the magnitude of the voltage
to be measured is not known beforehand, select the highest
range and then reduce it range by range until satisfactory
resolution is obtained.
Connect the test leads across the source or circuit to be
measured.
Read LCD display. For DC voltage measurements, the polarity of
red lead connection will be indicated as well.
To avoid electric shock to you or damage to the meter, do not
attempt to measure DC voltage higher than 300 V or AC voltage
higher than 300 V RMS although readings may be obtained.
1.
2.
3.
4.
5.
Measuring DC or AC Current
Set the range switch to desired "μΑ ", "mA " or "10A "
range. For both autorange mode and manual range mode, select
the highest range and then reduce it range by range until
satisfactory resolution is obtained if the magnitude of the
current to be measured is not known beforehand.
1.
22
OPERATING INSTRUCTIONS
NOTE:
