Measuring Resistance
Connect the black test lead to the "COM" jack and the red test
lead to the "VΩHz " jack (Note: The polarity of the red lead is
positive " + " ).
Set the range switch to Ω range.
Connect test leads across the load to be measured.
Read the reading on the display.
1.
2.
3.
4.
For resistance above 1 MΩ, the meter may take a few
seconds to stabilize reading. This is normal for high
resistance measuring.
When the input is not connected, i.e. at open circuit, "OL"
will be displayed for the overrange condition.
Before measuring in-circuit resistance, make sure that the
circuit under test has all power removed and all capacitors
are fully discharged.
1.
2.
3.
24
OPERATING INSTRUCTIONS
NOTE:
