MasterCraft 052-1899-2 User Manual

RESISTANCE
Overload Protection: 300 V DC/AC
Open Circuit Voltage: about 0.25 V
RANGE
400 Ω
4 kΩ
40 kΩ
400 kΩ
4 MΩ
40 MΩ
0.1 Ω
1 Ω
10 Ω
100 Ω
1 kΩ
10 kΩ
± (1.0% + 5)
± (1.0% + 3)
± (2.0% + 5)
RESOLUTION ACCURACY
Overload Protection:
For "mA°C" jack inputs: Fuse, 500 mA/300 V, fast action
For "10 A" jack inputs: Fuse, 10 A/300 V, fast action
Max. Input Current: 10 A (For inputs > 5 A: measurement
duration<10 secs, interval >15 minutes)
Max. Voltage Drop: 400 mV
Frequency Range: 40 – 400 Hz
Response: Average, calibrated in RMS of sine wave
model no. 052-1899-2 | contact us 1-800-689-9928
15
TECHNICAL SPECIFICATIONS

MasterCraft 052-1899-2 Specifications

General

Brand	MasterCraft
Model	052-1899-2
Category	Multimeter
Language	English
