20V max* LITHIUM-ION CORDLESS CIRCULAR SAW - 054-8332-4
OPERATING INSTRUCTIONS
WARNING!
If the blade comes in contact with the workpiece before it reaches full speed, it could cause
the saw to “kickback” towards you, which could result in serious injury.
To adjust the bevel angle (g 13)
1. Remove the battery pack from the saw.
WARNING!
Do not bind the blade in the cut. It
could cause the saw to “kickback”
towards you, which could result in
serious injury.
2. Loosen the bevel-adjustment knob, located on the 0–50° bevel scale on the base plate.
3. Tilt the body of the saw until the required angle is reached (refer to the bevel scale).
4. Tighten the bevel-adjustment knob to secure the saw and bevel angle.
Making a bevel cut (g 14)
fig 13
fig 14
