MasterCraft 055-6715-4 - Parts List

19
WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of any other parts
may create a safety hazard or cause damage to the scroll saw.
Any attempt to repair or replace electrical parts on this scroll saw may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline, at
1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
SBS16B-01
Chip shield
1
2
SBS16B-02
Hold-down foot
1
3
SBS16B-03
Screw
1
4
SBS16B-04
Spring washer
1
5
SBS16B-05
Flat washer
1
6
SBS16B-06
Screw
1
7
SBS16B-07
Height adjustment rod
1
8
SBS16B-08
Blower hose
1
9
SBS16B-09
Blower hose
1
10
SBS16B-10
Height adjusting knob
1
11
SBS16B-11
Screw
1
12
SBS16B-12
Nut
1
13
SBS16B-13
Bushing
4
14
SBS16B-14
Left rocker cover
1
15
SBS16B-15
Air cell plate
1
16
SBS16B-16
Lower blade holder
1
17
SBS16B-17
Lower rocker
1
18
SBS16B-18
Spring
1
19
SBS16B-19
Adjustable lever
1
20
SBS16B-20
Upper rocker
1
21
SBS16B-21
Adjustable piece
2
22
SBS16B-22
Pressure plate
2
23
SBS16B-23
Tension knob
1
24
SBS16B-24
Spring washer
1
25
SBS16B-25
Flat washer
1
26
SBS16B-26
Screw
1
27
SBS16B-27
Right rocker cover
1
28
SBS16B-28
Screw
7
29
SBS16B-29
Lamp
1
30
SBS16B-30
Screw
4
31
SBS16B-31
Bracket plate
2
32
SBS16B-32
Screw
2
33
SBS16B-33
Flat washer
2
34
SBS16B-34
Air bellows
1
35
SBS16B-35
Upper blade holder
1
PARTS LIST
!
