TABLE OF CONTENTS
Rules for Safe Operation……………..……………………….......… Page 3
Glossary of Woodworking Terms…………………………………… Page 8
Description ………………………………......…………………….. Page 10
Assembly……………………......…….......….…………….....…… Page 12
Adjustments............................................……………...........……… Page 12
Operation...................…………………....………………………… Page 22
Maintenance........................................………………..…………… Page 30
Loose Part........................................………………..…………......… Page 31
Troubleshooting....................................…………………………… Page 32
Exploded View & Part List.........................……..…………………… Page 34
Warranty………………………………………………….................. Page 44
SPECIFICATIONS
Rating: 120 V~, 60 Hz, 13 A,
No Load Speed: 5000 RPM (no load)
Blade size: 10” (254 mm) (36-tooth) carbide-tipped
Arbor size: 5/8” (16 mm)
Blade tilt: 0º-45º
Cutting Depth at 0°: 3” (76.2 mm)
Cutting Depth at 45° 2 1/2” (64.0 mm)
Weight: 45 lb 2 oz (20.5 kg)
