MasterCraft 55-6896-2 User Manual

2
TABLE OF CONTENTS
Rules for Safe Operation…………..……………………………….......Page 3
Glossary of Woodworking Terms……………………………................Page 9
Description…………..…………………………………………..........Page 10
Assembly…………..…………………………………………........... . . Page11
Adjustments…………..…………………………………………........Page 11
Operation…………..………………………………………….............Page 14
Maintenance…………..………………………………………............Page 23
Troubleshooting…………..……………………………………...........Page 24
Repair Parts…………..……………………………………................ Page 25
Exploded View & Part List…………..……………………...................Page 26
Warranty…………..……………………………………………..........Page 32
SPECIFICATIONS
Mitre Saw Specifications:
Model: 55-6896-2
Motor: 120 V 60 Hz 15 A,
Speed: 5500 RPM, no load
Blade: 10˝ (25.4 cm) (40-tooth) carbide-tipped
Laser: CLASS llla
Laser wavelength: 635-655 nm
Laser max outpower: 2.5 mW
sliding length: 8 1/4”
Weight: 38 lb 9 oz (17.5 kg)
Cutting capacity: 3 1/8 x 11 5/8”crosscut at 0º mitre, 0º bevel
3 1/8 x 8˝ mitre at 45º mitre, 0º bevel
1 1/2 x 11 5/8˝ at 0º mitre, 45º bevel
1 1/2 x 8˝ compound at 45º mitre, 45º bevel

MasterCraft 55-6896-2 Specifications

General

Brand	MasterCraft
Model	55-6896-2
Category	Saw
Language	English
