MasterCraft 55-6896-2

27
Parts List
No Description Quantity
1 Screw 2
2 Motor cover 1
3 Screw 4
4 Brush 2
5 Brush spring 2
6 Brush hold 2
7 Screw 4
8 Spring washer 4
9 Washer 4
10 Motor housing 1
11 Rubber boot 1
12 Wave washer 1
13 Bearing 1
14 Armature 1
15 Stator 1
16 Washer 2
17 Spring washer 2
18 Screw 2
19 Fan baffle 1
20 Bearing 1
21 Gear lock pin spring 1
22 Gear lock pin 1
23 Gear lock pin cap 1
24 Screw 2
25 Anti-finger touch plate 1
26 Gear case 1
27 Exhaust port 1
28 Screw 2
29 Nut 1
30 Knurled thin nut 1
31 Socket head screw 1
32 Depth of cut adjust knob 1
33 Screw 6
34 Lower handle 1
35 Cold clamp 1
36 Screw 3
37 Screw 1
38 Laser switch 1
