Technical Techniques

GEN 2 Wake Shaping Devices Installation

(Replacing GEN 1) for X2, X10, X25,

X30, and X46

(Page 10)

Raise Platforms:

For X30 and X46, use Steps 37 through 40; for X2 and X25 use Steps 41 through 43)

(X10)

 Platformremainsinsameposition.Noadditionaladjustmentisrequired.

(X30 and X46)

Step 39: Removetheplatform.

Step 40:Removetheupperbracket.

Step 41:InstallthenewbracketprovidedwiththeGEN2kit.Itwillraisetheplatformtwoinches(2”)abovethepreviouslocation.

Step 42:Reinstalltheplatformonthetransom.

(X2 and X25)

Step 43:Removetheplatform.

Step 44:Installtheprovidedspacersbetweenthebracketandthebottomoftheplatform.

Step 45: Reinstalltheplatform.Youwillneedlongerscrewsbecauseofthespacers.Usethreeinch(3”)longSSscrews.
