Installing Wiring:
Step 26:AttachtheDeutchconnectoronthewiringthatwasrunthroughthetran-
somandintothecloseoutarea.
Step 27: Connecttheactuatorharness,matchingwires,tothemainboatharness
drop,fromwhichtheGEN1wasconnected.
Step 28: Seal the wire hole throughthe boat with Bostick or another marine-
gradesealant.
Step 29: Attachtheactuatortothetransombracketusingthesuppliedhardware.
GEN 2 Wake Shaping Devices Installation
(Replacing GEN 1) for X2, X10, X25,
X30, and X46
(Page 7)
