Connecting the Actuator (all models):

Step 30: FortheX25,theLONGbracketwillbeusedtoattachtheactuatorto

thesurftabplate.

 Fortheothermodels,theSHORTbracketwillbeused.

Step 31: With the actuator fully extended, markthelocation forthe bracket

toattachtothewakeshapingdeviceplate.Using2-1/4X20X3/4SS

trussheadboltsand2-1/4X20Nylocknuts,attachthebracketbutkeep

loose.

Step 32:Keepingthebracketloose,installtheattachmentpinthroughthebrack-

etandactuatorend,placingablackspaceroneithersideoftheactua-

tor.Slidethepinallthewaythroughandcentertheactuatorwithinthe

bracket.

Step 33: Adjustthebracketsothattheactuatoriscenteredbetweenandtighten

thebrackettotheplate.

Technical Techniques

GEN 2 Wake Shaping Devices Installation

(Replacing GEN 1) for X2, X10, X25,

X30, and X46

(Page 8)
