ChargeMaster Plus 24/80-2, 24/110-2 – User and Installation Manual
7 TECHNICAL DATA
7.1 Specifications
Model
24/80-2
24/110-2
Product code
44320805
44321105
Nominal input voltage
120/240V
120/240V
Nominal input frequency
50/60Hz
50/60Hz
Full load consumption
2800VA
3800VA
Max. AC input current (@ 230VAC)
11.75A
15.75A
Max. AC input current (@ 120VAC)
23.0A
31.5A
Nominal output voltage
28.5V
28.5V
Total charge current*
80A at 28.8V
110A at 28.8V
Number of battery outlets
2
2
Max. current DC 2 OUT*
20A (24V) / 15A (12V)
20A (24V) / 15A (12V)
Charge characteristic*
IUoUo, automatic, 3-step+
Charge voltage Bulk*
28.8V
28.8V
Charge voltage Absorption*
28.5V
28.5V
Charge voltage Float*;
26.5V
26.5V
Max. absorption and max. bulk
timer*
8 hours (start max. bulk timer at 26.5V)
Minimum absorption time*
15 min.
15 min.
Maximum ripple voltage on DC
240mV pp
240mV pp
Battery type settings*
User defined, AGM, Gel, Flooded, Lithium-ion
Dimensions (mm)
383×252×126
383×252×126
Dimensions (inch)
15.1×9.9×5.0
15.1×9.9×5.0
Weight
6.3 kg (13.9 lbs)
6.3 kg (13.9 lbs)
Recommended battery capacity
280-700Ah
400-1000Ah
Power factor regulations
≥0,98
≥ 0,98
Temperature compensation
Yes, battery temperature sensor and cable included.
Voltage compensation
Yes, by means of automatic compensation or MasterShunt
DC consumption
<10mA
<10mA
Temperature range
–25°C (–13°F) to 80°C (176°F)
Derating 1%/°C (0,5%/°F) from 40°C (104°F) to 60°C (140°F);
Derating 8%/°C (4,4%/°F) from 60°C (140°F) to 70°C (158°F);
Communication available, 0% output power from 70°C
(158°F) to 80°C (176°F)
Cooling
Vario fan and natural cooling to ensure optimized cooling
Sound level
<60dBA / 1m
Protection degree
IP 23
IP 23
CZone connectivity
Yes
Yes
MasterBus connectivity
Yes
Yes
Powering capabilities for MasterBus
Yes
Yes
When the charger is switched on and AC is available, it can
power up to three non-powering devices.
Ignition protected
Yes, conforming to SAE J1171/ISO 8846
* Adjustable, see chapter 4 for settings
Specifications are subject to change without prior notice.
