4.2.5 Events – System automation
A CZone/MasterBus device can be programmed to initiate an action at another connected device. This is
very helpful in automation of your system but is not required. In MasterBus this is done by means of event
based commands. In the Events tab you can program the ChargeMaster Plus to act as an event source.
Events which occur during the operation of the ChargeMaster Plus will then trigger actions from other
products. The following tables list the parameters as shown in MasterAdjust.
Select an event that triggers an action, for example
Battery pre low.
Select the device that should act, for example the
generator
Selectable targets are
system dependent
Select the parameter that must be changed on the
target device, for example Activate.
See command list of the
selected device
Data, for example On, is linked to the command.
Off, On, Copy, Copy Invert,
Toggle
Table 1: MasterBus event parameters
The ChargeMaster Plus can be configured as an event source. An event source can be used to initiate
an event command and an event action by another device.
State of the ChargeMaster Plus serves as an event source
Bulk state of charge serves as an event source
Absorption state of charge serves as an event source
Float state of charge serves as an event source
Any fault condition of the ChargeMaster Plus serves as an event source
Table 2: ChargeMaster Plus MasterBus Event sources
When the ChargeMaster Plus is configured as an event target by another device, this device can initiate
an event command and an event action to be performed by the ChargeMaster Plus.
Command to switch on the ChargeMaster Plus
Command to start the Bulk state of charge
Command to start the Absorption state of charge
Command to start the Float state of charge
When using an MLI Ultra Li-ion battery, this event is obligatory. Refer to the MLI
Ultra manual.
Table 3: ChargeMaster Plus MasterBus Event commands
4.2.6 Current control
If the available power at the AC input is limited. The ChargeMaster can be configured to reduce input
current. The Current Control level should be set equal to or lower than the value of the external circuit
breaker, which protects the incoming AC power. For example, when the external AC power is limited by
a 6A fuse, the Current Control level should be set to ≤6A. The AC input current of the ChargeMaster Plus
will be reduced to 6A.
How to set the DC input current in a MasterBus network
1. Open MasterAdjust.
2. Select the ChargeMaster Plus.
3. Go to the Monitoring tab.
4. In the Input Current field, enter the required value.
