Mastervolt CHARGEMASTER PLUS 24/80-2

ChargeMaster Plus 24/80-2, 24/110-2 – User and Installation Manual
17
4.2.3 History
The history data shows the absolute maximum readings. The following parameters are only shown in
MasterAdjust.
Parameter
Meaning
Charger
Days running
Total run time in charger mode
DC 1 / 2 OUT
Total Ah’s
Total charged Ah’s
4.2.4 Configuration settings
The configuration can be done in MasterAdjust, from a laptop or notebook connected to the
ChargeMaster Plus via a Mastervolt USB Interface. See applicable user manuals for details. The following
table lists the parameters as shown in MasterAdjust.
Notes: - DIP switch settings overrule MasterBus settings. If DIP switches are not in their default setting,
the corresponding MasterBus setting is grayed out.
- To be able to make changes to the configuration via MasterBus, DIP switch 1 must be in the
ON position.
Parameter
Meaning
Factory
setting
Value range
Device
Language
Menu language of this device
English
EN, NL, DE, FR, ES, IT,
NO, SV, FI, DA
Name
Name of this device. This name will
be recognized by all devices
connected to the network
CHG CM+type
0-12 characters
Powersave
mode
If Powersave mode is ON, the
charger will switch itself off when no
AC power is available.
If Powersave mode is OFF, the
charger stays ON even when no AC
power is available.
On
On, Off
Charger
Method
Charge method
3-Step+
3-Step+, constant voltage
Maximum
current
Maximum DC output current
Depending on
model, 100%
Depending on model 20-
100%
Battery type
Type of battery
Flooded
User defined, AGM, Gel,
Flooded, Lithium-ion
Temp.
compensate
Temperature depended charge
voltage compensation
-0,060V/°C
-1,000/+1,000V/°C
DC 2 OUT
Output 2 operation mode
Current limit
Current limit, Constant
12V, Constant 24V, 12V 3-
Step+, 12V battery
Maximum
current
Output 2 maximum DC output current
20A
5-20A
