MASTERBUS SETTINGS
EN / Mass Charger 12/60-2; 12/80-2; 24/50-2; 24/75; 24/100; 3-24/100; 48/25; 48/50 / July 2010 19
Value Meaning Factory setting Adjustable range
7.6 FLOAT
Float voltage Float voltage 13.25, 26.50,53.00 V 0.00-16.00/16.00-
32.00/ 32.00-64.00 V
Equalize voltage Equalize voltage 15.50/ 31.00/ 62.00 V 0.00-16.00/16.00-
32.00/ 32.00-64.00 V
Equalize time Equalize time 360 min 0-600 min
7.7 ALARM SETPOINTS
DC Alrm high on Alarm DC High on 16.00/32.00/ 64.00 V 0.00-16.00/16.00-
32.00/ 32.00-64.00 V
DC Alrm high off Alarm DC High off 15.00/30.00/60.00 V 0.00-16.00/16.00-
32.00/ 32.00-64.00 V
DC Alrm low on Alarm DC low on 10.00/20.00/40.00 V 0.00-16.00/16.00-
32.00/ 32.00-64.00 V
DC Alrm low off Alarm DC low off 11.00/22.00/44.00 V 0.00-16.00/16.00-
32.00/ 32.00-64.00 V
DC Alrm delay Alarm delay time 30 sec 0-255 sec
7.8 TRACTION SETTINGS
Bulk voltage Bulk voltage 14.60/29.20/58.40 V (read only)
Max bulk time Maximum bulk time 360 min (read only)
Min bulk time Minimum bulk time 4 min (read only)
Start bulk time Start bulk time 13.80/27.60/55.20 V (read only)
Bulk ret. volt. Bulk return voltage 12.80/25.60/51.20 V (read only)
Bulk return time Bulk return time 30 sec (read only)
Abs. voltage Absorption voltage 14.45/28.90/57.80 V (read only)
Max absorp. time Maximum absorption time 480 min (read only)
Min absorp. time Minimum absorption time 15 min (read only)
Return amps Return to Bulk current (in A) 6.0 %*I max (read only)
Float voltage Traction float voltage 13.25/26.50/53.00 V (read only)
7.9 NICAD SETTINGS
Bulk voltage Bulk voltage 14.5/29.00/58.00 V (read only)
Max bulk time Maximum bulk time 480 min (read only)
Min bulk time Minimum bulk time 2 min (read only)
Start bulk time Start bulk time 13.25/26.50/53.00 V (read only)
Bulk ret. volt. Bulk return voltage 10.00/20.00/40.00 V (read only)
Bulk return time Bulk return time 30 sec (read only)
Abs. voltage Absorption voltage 14.50/29.00/58.00 V (read only)
Max absorp. time Maximum absorption time 480 min (read only)
Min absorp. time Minimum absorption time 15 min (read only)
Return amps Return to Bulk current (in A) 6.0 %*I max (read only)
Float NiCad float voltage 13.00/26.00/52.00 V (read only)
7.10 LI-ION SETTINGS
Bulk voltage Bulk voltage 14.60/29.20/58.40 V (read only)
Max bulk time Maximum bulk time 480 min (read only)
Min bulk time Minimum bulk time 2 min (read only)
Start bulk time Start bulk time 13.25/26.50/53.00 V (read only)
Bulk ret. volt. Bulk return voltage 13.15/26.30/52.60 V (read only)
Bulk return time Bulk return time 240 sec (read only)
Abs. voltage Absorption voltage 14.50/29.00/58.00 V (read only)
Max absorp. time Maximum absorption time 480 min (read only)
Min absorp. time Minimum absorption time 15 min (read only)
Return amps Return to Bulk current (in A) 6.0 %*I max (read only)
Forced Float LI-ion forced float voltage 13.25/26.50/53.00 V (read only)
