GENERAL INFORMATION
4 July 2010 / Mass Charger 12/60-2; 12/80-2; 24/50-2; 24/75; 24/100; 3-24/100; 48/25; 48/50 / EN
1 GENERAL INFORMATION
1.1 USE OF THIS MANUAL
Copyright © 2010 Mastervolt. All rights reserved.
Reproduction, transfer, distribution or storage of part or all
of the contents in this document in any form without the
prior written permission of Mastervolt is prohibited.
This manual contains important safety and operating
instructions for the safe and effective operation,
maintenance and possible correction of minor
malfunctions of the Mass Charger.
It is therefore obligatory that every person who works on or
with the Mass Charger is completely familiar with the
contents of this manual, and that he/she carefully follows
the instructions and important safety instructions contained
herein.
1.2 VALIDITY OF THIS MANUAL
All of the specifications, provisions and instructions
contained in this manual apply solely to standard versions
of the Mass Charger delivered by Mastervolt.
This manual is valid for the following models:
Part no Model
40010606 Mass 12/60-2 (230 V)
40010806 Mass 12/80-2 (230 V)
40020506 Mass 24/50-2 (230V)
40020756 Mass 24/75-C (230V)
40021006 Mass 24/100-C (230V)
40031006 Mass 24/100 3-phase (3x400V)
40040256 Mass 48/25 (230 V)
40040506 Mass 48/50 (230 V)
These models are further mentioned as “Mass Charger”
For other models see other manuals available on our
website: www.mastervolt.com
1.3 USE OF PICTOGRAMS
Safety instructions and warnings are marked in this
manual by the following pictograms:
WARNING
A WARNING refers to possible injury to the
user or significant material damage to the Mass
Charger if the user does not (carefully) follow
the procedures.
CAUTION!
Special data, restrictions and rules with regard
to preventing damage.
A procedure, circumstance, etc which deserves
extra attention.
1.4 IDENTIFICATION LABEL
Figure 1: Identification label
The identification label is located at the right-hand side of
the Mass Charger (see figure 1). Important technical
information required for service, maintenance & secondary
delivery of parts can be derived from the identification
label.
CAUTION!
Never remove the identification label.
1.5 LIABILITY
Mastervolt can accept no liability for:
• consequential damage due to use of the Mass
Charger;
• possible errors in the manuals and their results.
Serial number
XD10A
0005
Apparatus version “A”
Part number
Design by
Mastervolt
Manufactured in China
Serial no: V822C0001
Part no : 44020800
Type : ChargeMaster 24/80-3
Input : 120/230V AC 50/60 Hz 26A/13A
Output : 28.5VDC - 80A
IP 23
Mass Char
e
24/100-C
220-240V 16A 50-60Hz
28.50V 100A
40021006
XD10A0005
